Technical parameters:
| Control mode | The controller adopts one control one mode |
| Positioning mode | Yes |
| Traffic frequency/ opening time | 0.5 seconds. 35-60 people/minute, depends on the people moving speed |
| Aisle width/ passage width | 600-900 mm. Free to order |
| Housing material | 304 stainless steel with hairline finish thinkness 2.0 mm |
| IP | 44 |
| Door wing material | Plexiglass (can add light source) |
| Infrared logarithm/ sensors | 6 pairs |
| Operating voltage | 220V +10%, 50Hz +/- 4% |
| Drive motor | 24VDC, 5A |
| Power Consumption | 100W |
| MCBF | More than 10,000,000 (ten million) cycles (Failure free) |
| Greeting and guidance audio | Yes |
| Fire alarm connection | Yes. Auto opening for exit while fire alarm signals are triggered |
| I/O, Host communication | For opening – K1, closing – K2, FIRE ALRM; Modbus RTU with 4 relays output upto 1200m |
| Operating temperature | -15 to 70 degree centigrate |
| Operating humidity | From 5 to 95 degree centigrate without condensation |
| Working environment | Both indoor and outdoor |
| Temperature increasing of motor | T 15 |
| Noise | Less than 50db |
| Light protection | 3 levels |
| Dimension | L1400*W300*H980mm; Dual movement: L1400*W450*H980mm |
| Net weight | 45 KG for Single core, 55 KG for Double core |
| Warranty | 12/24/36 months |
| Other functions: | Anti pinch, Anti follow, Auto reboot when collision force (Watch dog), mifare reader and face terminial integration ready |
